Cor-Ban 23

Zip-Chem® Cor-Ban® 23 is a long lasting, water displacing and high penetration corrosion inhibiting compound. It combines the fast dry time and thin film of BMS 3-23 with the long lasting corrosion inhibition of BMS 3-29 and BMS 3-35, and is used in place of Airbus CML 15-006. It forms a non-sagging, non-tacky, detectable thin film and is solvent removable. It is used on upper edge floor beams, wheel wells, pressure decks and centre wing sections.

Specifications

• BMS 3-23K Type II Class 2 Grade A and B (QPL), BMS 3-35, BAMS 565-006 Type V (QPL)
• AIMS 09-08-001 Type I Grade 3, DHMS C4.12 Type II Grade 3 and 4 (QPL), MEP 10-063 (QPL), Fed-Ex E.O. 9-5100-7-5001
• NSN 8030-01-531-7361 (355 mL aerosol), 8030-01-531-7362 (18.9 L pail)

Typical Properties

• Colour transparent reddish pink; non-volatiles 42%; flash point 46 °C
• Dry time under 1 hour; operating temperature −54 to 177 °C
• Dry film below 8 µm; salt spray over 3000 hours on aluminium

Application

• Dry film 7–12 µm; one aerosol covers approximately 14.9 m², bulk material 56.2 m²/L
