Zip-Chem® Cor-Ban® 23 Enhanced Dye is a long lasting, high penetration and water displacing corrosion inhibiting compound. Its stronger dye than regular Cor-Ban® 23 makes the film easy to detect visually. It forms a thin, fast drying, non-tacky, non-sagging film and is solvent removable. It may be used in place of Airbus CML 15-006. It is used on high profile aircraft substrates such as upper edge floor beams, wheel wells, pressure decks and centre wing sections.
Specifications
- BMS 3-23J Type II Class 2 Grade A and B (QPL), BMS 3-35
- AIMS 09-08-001 Type I Grade 3, BAMS 565-006 Type V, Fed-Ex E.O. 9-5100-7-5001
Typical Properties
- Colour transparent reddish pink; specific gravity 0.88; non-volatiles 42%; viscosity 35–40 cP
- Flash point 45 °C; dry time under 1 hour; operating temperature −54 to 177 °C
- Dry film below 8 µm; salt spray over 3000 hours on aluminium
Application
- Dry film 7–12 µm; one aerosol covers approximately 14.9 m², bulk material 56.2 m²/L
- Packaging: 473 mL aerosol, 18.9 L pail
| Packing | 16 OZ or 5 USG |
