Zip-Chem® Cor-Ban® 23 Undyed is a long lasting, water displacing, high penetration corrosion inhibiting compound. It forms a clear, transparent, non-tacky thin film. It dries fast, does not sag, and does not crack or flake down to −54 °C (−65 °F); it is solvent removable. It surpasses specification requirements with a dry film weight below 10 microns (0.4 mil).
Specification
- Cessna CSNP038 Type IVB Class 1 (QPL)
Use
- High profile aircraft structure: upper edge floor beams, wheel wells, pressure deck and centre wing sections
- Apply by conventional airless, air-operated spray equipment or aerosol; the aerosol can be used with Formit® extensions for hard-to-reach areas
- Properties achieved at 7–12 µm (0.3–0.5 mil) dry film; the wet film self-levels on an inclined surface
- Coverage: one aerosol approximately 14.9 m², bulk material approximately 56.2 m²/L (3.8 L)
Typical Properties
- Colour: clear and transparent; drying time under 1 hour; non-volatile content 42%
- Specific gravity 0.88; viscosity 26 cP; flash point 46 °C (114 °F)
- Salt spray on aluminium over 3,000 hours; penetration (BMS 3-35) over 4 inches per hour; water displacement: 0% rust
- Passes exfoliation and low temperature flaking tests at −54 °C
Packaging
- 355 mL (12 fl oz) aerosol, 3.8 L (case of 4), 18.9 L pail, 208 L drum
| Packing | 12 OZ or 1 USG or 5 USG or 55 USG |
