Hernon® Gasket Replacer 916 is a single-component, room-temperature-curing, gel-like anaerobic gasketing compound formulated to provide instant sealing. Once cured between mating metal flanges, filling voids in the surface, it provides a thin, flexible, solvent- and temperature-resistant seal. It can replace or be used as a dressing for conventional gaskets.
Benefits
- Instant sealing; reliable seal; no shrinkage due to solvent evaporation
- Excellent chemical resistance; eliminates the need for retorquing
Typical Properties
- Chemical type: methacrylate ester; appearance: red gel; specific gravity 1.13
- Maximum sealing pressure 5,000 psi; elongation 30%
- Gap filling: 0.254 mm (0.010 in) without primer; 0.050 in with primer
Cured Performance (24 hours at 22 °C)
- Shear strength (ISO 4587, grit-blasted steel) 7.5 N/mm² (1100 psi)
- Compressive shear strength (ISO 10123) ≥5.0 N/mm² (≥725 psi); tensile strength (ISO 6922) ≥8.5 N/mm² (≥1200 psi)
- Where cure speed is too slow or gaps are large, use EF Primer 49 or 50
Storage
- 8–28 °C in unopened containers
| Packing | 250 ML or 300 ML |
