LOCTITE 567 is a UL listed, off-white, low-break-out strength methacrylate thread sealant ideal for sealing coarse threads up to M80 / R3.
LOCTITE® 567 is an off-white, low strength, thixotropic methacrylate thread sealant. Cures by contact with metals when used in the absence of air and in threads up to M80 / R3. Most suitable for use in coarse metal threads and the removal torque value is 1.7 Nm. Viscosity 280,000-800,000 mPa s and operating temperature -55 to + 150 C It is UL approved.
Provides instant low pressure seal
It does not slip, pull or block in the system
One component - clean and easy to apply
Thixotropic and high / very high viscosity
UL approved
| Technical Data | |
|---|---|
| Viscosity 25°C mm2/s | 280.000 - 800.000 |
| Chemical Composition | Methacrylate ester |
| Storing Temperature | Room temperature |
| Application | Thread sealing |
| Curing Time | 5–20 min |
| Applicable Surfaces | Metal: steel |
| Strength | Low |
| Specific Gravity | 1,1 |
| General | |
| Packing | 50 ML or 250 ML |
| Color | White |
| Specifications & Approvals | |
| NSN · P/N · CAGE |
6850-01-166-0675
· LOCTITE 567
· CAGE Z5529
(TU)
6850-01-479-0487
· 567
· CAGE 05972
(TU)
8030-01-431-3582
· 567
· CAGE 05972
(TU)
|
| CAGE (Manufacturer) | Z5529 |
