Loctite 620

Loctite

High temperature retaining compound · up to 200 °C

Login to see price


$ 0.00 / Each
  • Packing
  • Color - Green
  • Viscosity 25°C mm2/s
  • Chemical Composition
  • Storing Temperature
  • Application
  • Curing Time
  • Applicable Surfaces
  • Strength
  • Specific Gravity

SHGM TR.TEDARİK.016 · ISO 9001:2015 · NCAGE TJ791


Technical Data Sheet (TDS)
Safety Data Sheet (SDS)

LOCTITE® 620 is a medium to high strength anaerobic retaining compound designed for bonding cylindrical fitting parts. It cures when confined in the absence of air between close fitting metal surfaces and prevents loosening and leakage from shock and vibration. Typical applications include locating pins in radiator assemblies, sleeves in pump housings and bearings in automatic transmissions. It is particularly suitable for applications requiring temperature resistance up to 200 °C. It is a one-component, high viscosity, green methacrylate ester liquid.

Typical Properties

  • Specific gravity (25 °C) 1.16; viscosity (Brookfield RVT, 25 °C, 20 rpm) 5000–12,000 mPa·s
  • Compressive shear strength (steel pins and collars): min 17.2 N/mm² after 24 hours at 22 °C; min 24.1 N/mm² after a further 24 hours at 177 °C
  • Coefficient of thermal expansion 80 x 10⁻⁶ K⁻¹; thermal conductivity 0.1 W/(m·K); elongation at break below 1%
  • 100% of initial strength retained after 1000 hours in motor oil at 125 °C and 95% in unleaded petrol at 22 °C

Use

  • Where cure speed is too slow or gaps are large, use Activator 7471™ or 7649™
Technical Data
Viscosity 25°C mm2/s 1.800
Chemical Composition Methacrylate ester
Storing Temperature 8 - 28 °C
Application Bearing assembly
Curing Time 80 min
Applicable Surfaces Metal: steel
Strength High
Specific Gravity 1,16
General
Packing 50 ML
Color Green
Specifications & Approvals
NSN · P/N · CAGE
6850-01-268-5917 · LOCTITE 620 · CAGE 05972 (BT)
8040-01-129-7171 · 620 · CAGE 05972 (BT)
CAGE (Manufacturer) 05972
​
