PPG PR-1440 Class A is an aircraft integral fuel tank sealant. Service temperature is −54 to 121 °C, with intermittent excursions up to 135 °C. It is designed for brush sealing of fasteners in fuel tanks and other fuselage sealing applications, and maintains elastomeric properties after prolonged exposure to jet fuel and aviation gasoline. It is a two-part, manganese dioxide cured polysulfide applied by brush in thicknesses up to 25 mils, curing at room temperature. Tests are run to AMS-S-8802 Class A methods.
Application Properties (A-1/2)
- Colour: A black, B off-white, mixed dark grey; mix ratio by weight 10:100
- Base viscosity 300 P (30 Pa·s)
- A-1/2: application life 1/2 hour; tack free under 10 hours; 35 Shore A in 30 hours
Performance
- Specific gravity 1.57; non-volatile content 86%; hardness 48 Shore A
- Peel: 156–165 N/25 mm after JRF, 142–156 N/25 mm after JRF/salt water, 100% cohesive
- Tensile strength 2241 kPa (325 psi); elongation 225%
- Weight loss 4.9% after 7 days in JRF at 60 °C; no corrosion after 20 days in JRF/salt water
- No cracking or loss of adhesion at −54 °C; repairable to itself
Storage and Packaging
- Kits and Semco cartridges: at least 9 months below 27 °C in unopened containers
- Pre-mixed and frozen Semco cartridges: at least 30 days below −40 °C
| Packing | 6 OZ / 100 ML or 1 PT |
