PPG PR-1764 Class B is an electrically conductive, corrosion inhibitive sealant. Service temperature is −55 to 121 °C, with intermittent excursions up to 182 °C. The cured sealant maintains electrical continuity in aircraft applications and provides long-term EMI/RFI protection; it protects against corrosion on aluminium alloys and between dissimilar metals and resists prolonged exposure to jet fuel and aviation gasoline. It is a two-part, nickel filled, manganese dioxide cured Permapol® P-3 polythioether, a low sag, thixotropic paste applied by extrusion gun or spatula. It is primed with PR-148 Adhesion Promoter. Tests are run to AMS 3266 Class B methods.
Application Properties (B-2)
- Colour: A black, B grey, mixed black; mix ratio by weight 15:100
- Slump: 11.43 mm initial, 10.16 mm at 90 minutes
- Application life 2 hours; tack free under 10 hours; 35 Shore A in 48 hours
Performance
- Specific gravity 2.15; non-volatile content 94%; hardness 55 Shore A
- Tensile strength 1517 kPa (220 psi); elongation 70%; tensile shear 1241 kPa
- Contact resistance 0.04 ohm; volume resistivity 0.10 ohm·cm
- EMI/RFI shielding effectiveness 70 dB at 1000 MHz; no corrosion after 2000 hours salt spray
Storage
- Semkit: at least 6 months at 4–16 °C
- Pre-mixed and frozen cartridge: 30 days at −40 °C or below
| Packing | 2.5 OZ or 4.5 OZ or 5 OZ |
