PPG PR-1770 Class B is a high strength aircraft integral fuel tank sealant. Service temperature is −55 to 180 °C. It is designed for fillet sealing of fuel tanks and other fuselage sealing applications, and maintains elastomeric properties after prolonged exposure to jet fuel and aviation gasoline. It is a two-part, manganese dioxide cured Permapol® P-5 polysulfide, a low sag, thixotropic paste applied by extrusion gun or spatula. Tests are run to AMS 3269 Class B methods.
Application Properties (B-1/2)
- Colour: A black, B light grey, mixed dark grey; mix ratio by weight 10:100
- Base viscosity 12,000 P (1200 Pa·s); slump 3.81 mm
- B-1/2: application life 1/2 hour; tack free under 10 hours; 30 Shore A in 24 hours
Performance
- Specific gravity 1.59; non-volatile content 98%; hardness 55 Shore A
- Peel: 200–222 N/25 mm after JRF, 258–307 N/25 mm after JRF/salt water, 100% cohesive
- Tensile strength 3654 kPa (530 psi); elongation 350%; 2654 kPa after 8 hours at 182 °C
- No cracking or loss of adhesion at −54 °C; no rolling or tearing when shaved or sanded
Storage
- At least 9 months below 27 °C in unopened containers
| Packing | 2.5 OZ or 6 OZ |
