PPG PR-1773 Class A is a low-adhesion, chromate-free, corrosion-inhibitive sealant with a service temperature range of −55 °C to 121 °C (−67 °F to 250 °F) and intermittent excursions up to 149 °C (300 °F). It is designed as an access door sealant and can also protect electrical wires, terminals and equipment against fuel, moisture, dirt and short circuits. A two-part, manganese dioxide cured polysulphide, it is brushable and will not drip or flow from vertical or overhead surfaces once applied around fasteners. The A-2 grade has a 2-hour application life.
Application Properties (23 °C, 50% RH)
- Colour: Part A black, Part B red, mixed dark red
- Mix ratio by weight A : B = 10 : 100; base viscosity 20–65 Pa·s (200–650 P)
- Application life 2 hours; tack-free 12 hours; cure to 30 Shore A 48 hours
Performance Properties (cured 14 days at 25 °C)
- Hardness 50 Shore A; cured specific gravity 1.55; non-volatile content 84%
- Low peel strength (easy removal): alclad 2024 aluminium 0.2 N/mm; stainless steel and titanium 0.1 N/mm
- Tensile strength 1.5 MPa; elongation 240%
- Excellent resistance to water, alcohols, synthetic and petroleum-based lubricating oils and petroleum-based hydraulic fluids
- Corrosion: no corrosion after 5000 hours salt spray or galvanic cell testing (Al/stainless, Al/titanium, Al/cadmium-plated steel); no cracking at −55 °C
Storage
- 6 months at 4–27 °C in original unopened containers; two-part kits and SEMKIT® cartridges
| Packing | 6 OZ |
