PPG PR-1776 Class A AS is a low-density, high-temperature integral fuel tank sealant: a two-part, manganese dioxide cured PERMAPOL® P-5 modified polysulfide. Class A is brushable; A-2 denotes a 2-hour application life.
Features
- Service temperature -55 to 95 °C (-67 to 203 °F), intermittent to 180 °C (356 °F)
- For fillet sealing of fuel tanks and other fuselage sealing; does not drip from vertical or overhead surfaces once applied around fasteners
- Retains elastomeric properties after prolonged exposure to jet fuel and aviation gasoline
- Room-temperature cure; excellent adhesion to common aircraft substrates
Application Properties (A-2, 23 °C / 50% RH)
- Colour: Part A black, Part B white, mixed grey
- Mix ratio by weight A : B = 10 : 100
- Application life 2 hours; tack-free 12 hours; 30 Shore A in 30 hours
Performance (typical)
- Cured specific gravity 1.3; ultimate hardness 50 Shore A
- Peel strength (100% cohesive): aluminium 7.0 N/mm, stainless steel 6.0, titanium 5.5
- Tensile strength 2.0 MPa, elongation 450% (initial)
- Flexible at -55 °C; excellent repairability; PR-148 AF recommended as adhesion promoter
| Packing | 6 OZ / 100 ML or 1 PT |
