PPG PR-1782 Class A is a low density aircraft fuel tank and general purpose sealant. Service temperature is −54 to 121 °C. It is designed for brush sealing of fasteners in fuel tanks and other fuselage sealing applications, and offers up to 30% weight savings per unit volume over traditional sealants. It is a two-part, manganese dioxide cured polysulfide applied by brush in thicknesses up to 25 mils. Tests are run to AIMS 04-05-012 and AIMS 04-05-001.
Application Properties (A-2)
- Colour: A black, B blue, mixed mid grey; mix ratio by weight 12:100
- Base viscosity 1200 P (120 Pa·s)
- Application life 2 hours; tack free under 8 hours; 35 Shore A in 12 hours
Performance
- Specific gravity 1.11; non-volatile content 88%; hardness 52 Shore A
- Tensile strength 1.7 MPa; elongation 350%
- Dry peel (aluminium, titanium, stainless steel) 169–182 N/25 mm, 100% cohesive
- Shear strength 1.6 MPa (230 psi)
Storage
- Semkit: at least 6 months below 25 °C
- Pre-mixed and frozen cartridge: maximum 30 days at −40 °C or below
| Packing | 150 ML or 500 ML |
