PPG PR-1826 Class A is a two-part, rapid curing, polythioether based integral fuel tank sealant. It is applied by brush in thicknesses up to 0.6 mm (25 mils) without dripping or flowing from vertical or overhead surfaces, and cures at temperatures down to −18 °C. When primed with PR-1826 Adhesion Promoter it adheres to common aircraft materials. The cured sealant resists 149 °C, and 216 °C for short exposures, and stays flexible down to −62 °C. It resists aviation fuels, petroleum based oils and diphosphate ester type hydraulic fluids.
Application Properties
- Colour: accelerator black, base light tan; mix ratio by weight 8.2:100
- Non-volatile content 85%; viscosity 400 P (40 Pa·s)
- A-2: application life 2 hours; cure to 25 Rex in 16 hours
Performance
- Specific gravity 1.45; hardness 43 Shore A
- Tensile strength 2760 kPa (400 psi); elongation 350%
- Peel (7 days, 60 °C): 142–164 N/25 mm after JRF, 200–218 N/25 mm after JRF/3% salt water, cohesive
- After 2 hours at 216 °C tensile 1242 kPa, elongation 140%; passes flexibility at −62 °C
Storage
- At least 9 months at 4–27 °C in unopened containers
| Packing | 6 OZ |
