PPG PR-2201 Class B is an electrically conductive, rapid cure, non-chromated corrosion inhibitive sealant. Service temperature is −55 to 121 °C, with intermittent excursions up to 182 °C. The cured sealant provides excellent electrical conductivity and EMI/RFI shielding effectiveness, acts as a barrier against corrosion on aluminium alloys and between dissimilar metals, and resists jet fuel and aviation gasoline. It is a two-part, nickel filled, epoxy cured Permapol® P-3.1 polythioether, a low sag, thixotropic paste applied by extrusion gun or spatula. It adheres well to common aircraft substrates when primed with PR-188 Adhesion Promoter.
Application Properties (B-1)
- Colour: A black, B grey, mixed black; mix ratio by weight 7.77:100
- Slump 5.08 mm at 60 minutes
- B-1: application life 1 hour; tack free under 3 hours; 35 Shore A in 5 hours
Performance (cured 7 days at 25 °C)
- Specific gravity 2.0; non-volatile content 97%; hardness 60 Shore A
- Lap shear (MIL-C-5541) 937 kPa; tensile strength 894 kPa; elongation 100%
- Electrical contact resistance 0.038 Ω; 0.76 Ω after 1000 hours salt spray
- No corrosion or significant change of conductivity after 2000 hours salt spray
- No corrosion in galvanic cell tests with titanium, stainless steel and cadmium couples on aluminium
Storage
- At least 6 months below 27 °C in Semkit packages, unopened
| Packing | 2.5 OZ |
