Zip-Chem® Sur-Prep® D-5695NS is an alcohol cleaner for aircraft fire detection system connectors. It delivers an uncontaminated, ultra-filtered stream of electronic-grade methanol (methyl alcohol) to the exact area where it should be applied. It is used in avionics shops to clean connectors, PC boards and miscellaneous parts.
Use
- Spray the connector liberally and allow it to dry, so that the mating connector is clean and dry before installation
- Drying can be accelerated with Sur-Prep® 5604 Vapor-Duster
- Use the extended tube for pinpoint application and a Formit® wand for geometries such as tubing
- Not for use on activated circuits because of flammability risks
Typical Properties
- Component: methanol; propellant: CO₂; volatiles 100%
- Boiling point 64 °C (148 °F); flash point 15 °C (60 °F); freezing point −98 °C (−144 °F); specific gravity 0.8
Packaging
- 12 × 473 mL (16 fl oz) aerosols · 4 × 3.8 L (1 gal) cans · 18.9 L (5 gal) pail · 208 L (55 gal) drum
| Packing | 16 OZ or 1 USG or 5 USG or 55 USG |
