Patco 152 is a general-purpose, single-coated PVC film tape with a rubber-based adhesive (R306), for colour coding, marking and wrapping. It meets A-A-1689B Type II (supersedes PPP-T-66E Type 1 Class 2).
Features
- PVC film backing, conformable to irregular surfaces
- Excellent solvent, chemical, moisture and abrasion resistance
- Rubber-based adhesive with a strong bond to smooth and irregular surfaces
- Smooth, controlled unwind; clean removal
Applications
- Colour coding and striping
- Aisle and floor marking
- Harness and spiral wrapping
- Identifying safety equipment and hazards
- Duct and joint sealing; decorative masking
Typical Values
- Total thickness: 6.0 mils (0.152 mm)
- Adhesion to steel: 18 oz/in (1.97 N/cm)
- Tensile strength: 18 lb/in (31.52 N/cm)
- Elongation: 250%
- Application temperature: -10 to 60 °C
- Operating temperature: -29 to 80 °C
Specifications / Storage
- A-A-1689B, Type II
- Colours: black, brown, purple, red, orange, white, yellow, blue, green
- Shelf life 12 months from shipment; store at 60–80 °F, 40–60% RH
| General | |
|---|---|
| Color | Blue or Yellow or Red |
| Uncategorized | |
| Tape Size | 2in x 108ft or 1in x 108ft |
