Patco 1800 is a black, single-coated, flame-retardant PVC film galley tape for aircraft wet-seal applications in main cabin areas such as galleys, lavatories and entryways that are susceptible to moisture. It also serves as a corrosion barrier and is compatible with most sealants.
Specifications
- FAR 25.853(a) Appendix F for interior aircraft use
- Fokker FK05-159 and FK05-160
- Bombardier 91-25-1 to 91-25-6
Typical Values
- Total thickness: 0.241 mm (9.5 mils); backing thickness 0.216 mm (8.5 mils) (PSTC-133)
- Adhesion to steel: 5.47 N/cm (50 oz/in) (ASTM D3330); tensile strength: 43.78 N/cm (25 lb/in) (ASTM D3759)
- Puncture resistance: 5.44 kg (12 lb) (ASTM D1000); elongation: 200%; abrasion index: 34 (ASTM D4060)
- Application temperature: 10–49 °C; operating temperature: −40 to 93 °C
Construction
- Backing: PVC film, tough, conformable and moisture resistant
- Liner: coated kraft paper, die-cuttable with clean release
Storage
- 16–27 °C (60–80 °F) at 40–60% RH; shelf life 12 months from shipment at 25 °C
| Tape Size | 4" RL or 24" RL or 2" RL or 3" RL |
