Patco D9100 is a flame retardant waterseal and corrosion inhibiting tape with an interior grade aromatic polyurethane backing. It is used as a moisture barrier in aircraft interior structures and protects and holds under heavy usage. NSN 8030-01-542-1415.
Specifications
- FAR 25.853(a), BMS 8-346 Type I and II Class 1, Airbus 10-05-004, ABS 5093, ABD 0031 para 7.3.2/7.4, Fokker Fk05-193
Typical Properties
- Thickness 0.229 mm; weight 291.59 g/m²
- Adhesion 4.38 N/cm; tensile 122.59 N/cm; elongation 600%
- Puncture resistance 11.34 kg; abrasion index 0.98
- Service temperature −54 to 148 °C
| Packing | 3" RL or 4" RL or 18" RL or 24" RL or 36" RL or 2" RL |
