Polyken 225FR is a flame retardant duct tape with a PE coated cloth backing and a natural rubber based adhesive. It is used in cargo pit applications for freight aircraft, seaming and repairing cargo compartment liner panels, covering pins and rivets, and for patching, sealing and bundling. It offers high tensile strength for difficult applications, is extremely conformable and tears crisply and straight. It is moisture, solvent and abrasion resistant, adheres aggressively to all surfaces and resists flagging and lifting. It is Deca-BDE free, complies with FAR 25.853(a)(1)(i) and meets the requirements for use in aircraft cargo compartments.
Specifications
- FAR 25.853(a)(1)(i); DMS 1968E; FK05-006; FK05-113; Lockheed LCP-86-1226-A
Typical Properties
- Total thickness 0.305 mm; adhesion to steel 4.38 N/cm; tensile strength 50.79 N/cm
- Operating temperature 4 to 93 °C
- Burn test (FAR 25.853): burn length 5.5 in, flame time 15 s
- Standard sizes 48 mm × 55 m and 72 mm × 55 m; white, printed
Storage
- Shelf life 24 months from manufacture at 25 °C; at 40–60% relative humidity
| Tape Size | 48mm x 50mt |
