Sandstrom #329

Sandstrom #329 is a single-component, waterborne, inorganic heat-curing dry film lubricant qualified to MIL-PRF-81329, intended for metal components operating in environments where organic materials are not desired.

Features:

• Inorganic sodium silicate binder with molybdenum disulfide/graphite lubricating pigment
• Operating temperature range of -320°F to +750°F (-196°C to +399°C)
• Low coefficient of friction
• Applicable to a wide variety of metals by spraying, dipping or brushing

Applications:

• Extreme environments
• Liquid oxygen (LOX) systems
• Space vehicles
• Bearing assemblies

Specifications / Approvals:

• MIL-PRF-81329
• PWA 298 (qualified)

Typical Properties:

• Colour: Matte gray
• Weight solids: 50–56%
• Viscosity: 80–110 KU at 77°F (25°C)
• Recommended dry film thickness: 1.0–1.4 mil (25–36 µm)
• Theoretical coverage: 340 sq ft/gal at 1.0 mil DFT (approx. 8.3 m²/L at 25 µm)
• Coefficient of friction: static 0.0788, dynamic 0.0349
• Cure: 30 min flash-off at 77°F (25°C), then 2 h at 175°F (79°C), then 2 h at 300°F (149°C)
• Operating temperature: -320°F to +750°F (-196°C to +399°C)
